The global photonic quantum community gathered in Glasgow on Monday as the Optica Quantum 2.0 Conference and Exhibition opened its doors at the Scottish Event Campus, drawing scientists, engineers, and commercial players from across the quantum supply chain for a four-day program that runs through June 18. The opening sessions addressed foundational quantum optical systems, chip-scale entanglement generation, and single-photon sources — and the single engineering challenge threading through every one of them is the same: building quantum networks and quantum computers requires detecting individual photons with accuracy and speed that current hardware struggles to supply at any practical scale.
That bottleneck has a name. Superconducting nanowire single-photon detectors, or SNSPDs, are currently the fastest and most efficient single-photon detectors available. They are also cryogenic instruments that must be held near absolute zero — typically between 1 and 2.5 Kelvin — to function. Every quantum network node that relies on single-photon detection must also house and operate a cryostat. At roughly €100,000 per multichannel commercial system, this is the engineering reality behind the scaling question that the conference's four days of sessions are built around.
What Is Quantum 2.0 — and Why Does the Engineering Get Harder at Scale?
Quantum 2.0 is the shorthand researchers and governments use for the second quantum revolution: the deliberate engineering of quantum superposition and entanglement not in isolated laboratory systems, but across large-scale connected arrays — quantum computers and simulators, quantum communication networks spanning cities and satellites, and coordinated sensor arrays that exceed the measurement limits imposed by classical physics. The first quantum revolution, Quantum 1.0, gave the world lasers, transistors, MRI machines, and GPS — technologies that exploited quantum effects at the ensemble level. Quantum 2.0 is different because it requires controlling individual quantum states, preserving them long enough to be useful, and linking them across distances without losing the information they carry.
The engineering challenges multiply at every level of scale. A single trapped-ion qubit is a precision instrument. A networked cluster of thousands of them, connected by photonic links, is a different class of problem entirely — one that requires reliable photon generation, ultra-low-loss transmission, and detection that knows not just whether a photon arrived, but how many arrived simultaneously. That last requirement, photon-number resolution, is where much of the conference's technical energy is focused.
How a Superconducting Nanowire Detects a Single Photon
The operating principle of an SNSPD is elegant and unforgiving. A nanowire of superconducting material — typically niobium nitride (NbN), about 100 nanometers wide and patterned in a meandering geometry across an active detection area — is cooled below its critical temperature and held there while a direct current just below its critical threshold flows through it. The wire is, in this state, a superconductor: zero electrical resistance. When a single photon strikes the wire, it deposits enough energy to break the Cooper pairs in a localized region, creating a small resistive hotspot. The bias current, unable to flow through the hotspot, diverts around it, briefly disrupting the superconductivity and generating a voltage pulse that can be read by room-temperature electronics with timing precision measured in picoseconds.
A conventional SNSPD gives a binary answer: photon detected, or not. It cannot distinguish whether one photon arrived or three. That distinction matters enormously for quantum computing architectures that use photons as qubits, because linear optical quantum computing — one of the major photonic paths to fault-tolerant quantum processors — requires knowing the exact photon number arriving at each detector to perform the gate operations and error-correction steps that make computation reliable.
ID Quantique, now an IonQ company, has developed a parallel-pixel SNSPD architecture that addresses this directly. In a 28-pixel parallel design, each pixel is an independent threshold SNSPD. When photons arrive simultaneously, they trigger proportionally more pixels, generating a combined voltage step whose height encodes the photon count. The company's current commercial system achieves a system detection efficiency of 92.5% and detection rates exceeding one billion photons per second — performance specifications that the conference will examine in the context of photonic quantum networks that must sustain those rates continuously, not just in controlled laboratory bursts.
Thomas Produit, PhD, an application scientist at ID Quantique, is scheduled to present the company's work on Wednesday, June 17, at 11:30 AM BST, in a talk titled "Ultrafast and Photon-number resolving SNSPDs as enablers for quantum networks and photonic quantum computers."
Chip-Scale Entanglement and the Case for Photonic Integration
The conference's opening-day focus on chip-scale entanglement generation points to the manufacturing question underneath the physics. Photonic integrated circuits — PICs — allow quantum optical components to be fabricated on silicon or indium phosphide wafers, using the same process technology that reduced classical computing from room-filling machines to pocket-sized chips. On a silicon PIC, waveguides guide photons through the circuit with minimal loss; beam splitters and phase shifters perform quantum operations; photon sources based on quantum dots or parametric down-conversion generate the entangled photon pairs that the network distributes.
The promise of PICs for quantum networking is the same promise they delivered for telecommunications: if you can put the entire optical system on a single chip, you can fabricate it in volume, drive down costs, and distribute it widely. The challenge is yield and precision. A classical optical network tolerates manufacturing variability that a quantum network cannot — because quantum states are fragile, and a fabrication error that shifts a waveguide's resonant frequency by a few nanometers can destroy the interference conditions on which quantum gate operations depend.
G&H, the precision photonics manufacturer exhibiting at Booth 115, has identified scalable photonics manufacturing as the specific challenge it is positioned to address — a signal of where the industry's attention has shifted from proof-of-concept components to volume production. The company is presenting optical components and assemblies for quantum communications, sensing, and computing platforms.
From Lab to Supply Chain: The Industry Summit's Commercial Mandate
Running concurrently on Tuesday and Wednesday, the Optica 2026 Quantum Industry Summit — now in its fifth year — adds an explicitly commercial layer to the week. The Summit is designed as a meeting point between quantum companies and the supply chain partners who must eventually produce, at scale, the lasers, optics, photonic integrated circuits, detectors, and cryogenic hardware that quantum systems require.
Menlo Systems is also exhibiting, presenting precision photonics and laser solutions tailored to quantum technology applications.
The Summit's framing around "supply chain partners" is pointed. The quantum industry has passed the stage where bespoke, one-of-a-kind laboratory equipment is adequate. Reliability, yield, and volume — the unglamorous engineering preconditions for any real industry — are now the problems on the table. Researchers at the University of Colorado Boulder recently described a newly developed CMOS-fabricated photonic chip for laser frequency control as one of "the final pieces of the puzzle" for achieving a "truly scalable photonic platform capable of controlling very large numbers of qubits" — a candid reminder of how many such pieces remain.
Quantum Key Distribution From the Ground to Orbit
Session 9 on Wednesday afternoon — "Terrestrial and Space-Based Quantum Communications," scheduled from 4:15 to 5:45 PM BST — addresses one of the field's most consequential open problems: how to distribute quantum keys over distances that exceed what optical fiber can reliably handle. Quantum key distribution uses the quantum properties of individual photons to create encryption keys whose security is guaranteed by physics rather than computational hardness — any eavesdropper disturbs the photon states in ways that the communicating parties can detect.
The problem is distance. In optical fiber, photon loss increases exponentially with length. Terrestrial QKD links have been demonstrated over hundreds of kilometers, but continental- and intercontinental-scale deployment requires a relay mechanism. Satellites in low-Earth orbit, positioned above most of the atmosphere, offer dramatically lower transmission loss than terrestrial fiber over the same point-to-point distance. ID Quantique is participating in this session, where the maturation of satellite-based QKD from experimental demonstration toward operational national infrastructure is on the agenda. The company recently deployed Slovakia's first national quantum communication network, providing a working example of what continental-scale quantum networking infrastructure looks like in practice.
The UK's investment context is not incidental here. In March 2026, the UK government announced a £2 billion quantum technologies program, including £125 million dedicated specifically to quantum networking and a first-of-its-kind procurement program, ProQure, designed to support the scaling of quantum computing systems from laboratory prototypes to national infrastructure. Hosting the Optica Quantum 2.0 conference in Glasgow is, in that context, consistent with a deliberate national strategy: Scotland and the broader UK want to be where the quantum supply chain is built, not just where the physics was discovered.
Honoring Joseph Eberly
The conference includes a memorial session for Joseph Eberly, who died on April 30, 2025, at the age of 89. A professor at the University of Rochester for more than six decades, Eberly was among the founding theorists of quantum optics. His contributions include the first description of the spontaneous collapse and revival of quantum coherence, the first characterization of Bessel beams, and the identification of what he termed "sudden death" in quantum entanglement — the phenomenon by which two entangled systems can lose their entanglement abruptly rather than gradually. He served as president of Optica and founded Optics Express, one of the first open-access scientific journals in the field. The session brings together former students and collaborators to present current work and reflect on the research tradition he built.
Glasgow's Stake in the Quantum Age
The choice of Glasgow is deliberate. Glasgow City Council is a formal partner and co-sponsor of the event. The University of Glasgow's James Watt Nanofabrication Centre — one of the UK's premier academic nanofabrication facilities — is hosting an optional lab tour on Thursday, along with a visit to the ANALOGUE suite. ANALOGUE, which stands for the Automated Nano AnaLysing, characterisatiOn and additive packaGing sUitE, is a £3 million EPSRC-funded semiconductor packaging and characterization facility established at the Mazumdar-Shaw Advanced Research Centre. It is the UK's first machine-driven integrated assembly and characterization line for semiconductor devices — relevant because advanced packaging is what makes photonic and quantum chips manufacturable at anything resembling commercial scale.
Scotland has positioned itself as a node in the European quantum ecosystem, not merely a conference venue. The conference is one data point in a larger argument the country is making about where the quantum industry's hardware and supply chain will be built.
Frequently Asked Questions
What is Quantum 2.0, and how is it different from ordinary quantum computing?
Quantum 2.0 is the engineering regime in which quantum superposition and entanglement are deliberately engineered across large-scale, networked systems — quantum computers with thousands of connected qubits, national quantum communication networks, and arrays of quantum sensors. The term distinguishes this era from Quantum 1.0, which describes technologies that exploited quantum effects at the ensemble level — lasers, transistors, and MRI machines — without requiring control over individual quantum states. What makes Quantum 2.0 technically harder is that individual quantum states are fragile: they decohere rapidly, lose entanglement under interference, and are destroyed by measurement. Engineering systems that preserve and transmit these states at scale is the defining challenge of the field.
Why is single-photon detection a bottleneck for quantum networks?
Quantum networks transmit information encoded in the quantum states of individual photons. At every network node where that information is read out or relayed, a detector must register single photons with extremely high efficiency, very low noise, and precise timing. SNSPDs currently provide the best combination of these properties, but they require cryogenic operation near absolute zero — a multi-thousand-dollar infrastructure requirement for every detection node. More critically, photonic quantum computing architectures require detectors that can count exactly how many photons arrived simultaneously, not just whether any arrived. This photon-number-resolving capability is the specific technical frontier being addressed at the Glasgow conference.
What does quantum key distribution have to do with satellites?
Quantum key distribution over fiber works well over hundreds of kilometers, but photon loss in fiber increases exponentially with distance, making intercontinental QKD impractical without relay nodes. Satellites positioned in low-Earth orbit have dramatically lower transmission losses than fiber over equivalent distances, because most of the photon's path is through near-vacuum rather than glass. Satellite-based QKD can distribute encryption keys between ground stations thousands of kilometers apart by establishing separate keys with each station during successive overpasses. Multiple governments and telecoms operators are now developing operational satellite QKD infrastructure, making this session directly relevant to national security and communications policy.
Is Scotland specifically positioned to benefit from the global quantum industry?
Scotland's hosting of the Optica Quantum 2.0 conference, combined with the University of Glasgow's nanofabrication and semiconductor packaging infrastructure, reflects a concrete national strategy rather than coincidence. The UK government's £2 billion quantum program, announced in March 2026 and including £125 million specifically for quantum networking, makes the infrastructure question financially real. Glasgow City Council's formal co-sponsorship of the event signals civic investment in quantum as an industrial rather than purely academic priority.
